Metal Rollers
2.50" Dia. x .120" Wall Thickness - 7/16" Round Shaft
Bearings:
Type:
Stainless Steel
Steel, Commercial
ABEC-1 Precision
ABEC-1 Precision, SS
Stamped, Precision
Part #
2D2
2C9
3C8
3C8SS
33C8
Style / Description:
1 / Conductive plastic - Double labyrinth seal construction
1 / Conductive plastic - Double labyrinth seal construction
1 / Conductive plastic - Double labyrinth seal construction
1 / Conductive plastic - Double labyrinth seal construction
8 / ABEC-1 Precision in stamped zinc plated steel housing
Tube:
Materials:
Carbon Steel
Galvanized Steel
Stainless Steel
Part #
C56
G56
S56
Style / Description:
2.50" x .120" Wall Carbon Steel
2.50" x .120" Wall Galvanized Steel
2.50" x .120" Wall 304 Stainless Steel
Drive Options:
Cover Options:
Finish Options:
Shaft:
Materials:
Carbon Steel
Stainless Steel
Aluminum
** Plastic Adapters
*** Urethane Adapters
** Plastic Adapters
*** Urethane Adapters
Part #
C68
S70
A66
C62
UC62
S62
US62
Style / Description:
7/16" Hex Carbon Steel Shaft
7/16" Hex 304 Stainless Steel Shaft
7/16" Hex Aluminum Shaft
7/16" Hex External Adapter with 5/16" Hex Internal Carbon
Steel Shaft
7/16" Hex External Adapter with 5/16" Hex Internal Carbon
Steel Shaft
7/16" Hex External Adapter with 5/16" Hex Internal 304 Stainless
Steel Shaft
7/16" Hex External Adapter with 5/16" Hex Internal 304 Stainless
Steel Shaft
Standard Extensions:
Standard Springs:
Options:
